4 Gang 40x20mm Switch Flush Mount Panel

4 Gang 40x20mm Switch Flush Mount Panel

Fits Toyota 40x20 mm Switches only (not included), not compatible with USB units

Size of cut out for switches: 17mm (W) x 35.5mm (H)

Size of panel face: 137.2mm (W) x 51mm (H)

Mounting holes: 4.4mm (countersunk)

Mounting hole centres: 117.2mm (W) x 31.6mm (H)

Minimum cut-out required (for panel mounting): 105.3mm (W) x 44.7mm (H)

Please note: Please allow 1-2% tolerance on all measurements in accordance with manufacturing tolerances.
